Descrizione
L’impronta lasciata con la sonda UCI lascia è molto piccola rispetto alla maggior parte del tester di durezza da banco. Il tester di durezza T-UD2, non richiede alcuna ricalibrazione ed è completamente operativo “fuori dalla scatola”. Il metodo di misura con la sonda UCI è conforme alla normativa ASTM A1038, mentre la misura della durezza con la sonda Leeb è conforme alla normativa ASTM A956.
Specifiche tecniche:
UCI probe types 1kgf (10N) 2.2 lbf, 5kgf (50N) 11lbf, 10kgf (98N) 22lbf
Leeb probe types D, DC, DL, C, D+15, E, G
Measuring range HV:230~940; HRC:20~70; HB:90~650. Tensile strength, MPa 370~1740
Measuring accuracy HV:±3%HV; HRC:±1.5%HRC; HB:±3%HB
Standards ASTM A1038, ASTM A956, ASTM E140
Indenter Diamond indenter (UCI), Hardened ball (Leeb)
Measuring direction Any direction 360°
Hardness scale UCI probe – HRC, HB, HVLeeb probe – HRC, HB, HV, HRB, MPaAdditional custom scales for calibration.
Materials Ultrasonic (UCI) probe – pre-calibrated for steel.Dynamic (Leeb) pre-calibrated for steel, alloy steel, cast iron, stainless steel, aluminum, bronze, brass, copper.Additional custom materials for calibration.
Operating environment Temperature:-20°C~40°C; Humidity: 30%~80%R.H.
Power supply DC 4,5V (3 pcs batteries AA)
Instrument dimensions 120x60x25mm
Net weight Approx. 0.3kg (without probe)
Battery life Approx. 10 hours.
